HikVision DS-K1T6240 Series
The DS-K1T6240 Series is a portable access control device designed for secure and efficient face recognition. It features a 4.3-inch LCD touch screen and a 2-megapixel wide-angle lens, making it ideal for time attendance and access control in various environments.
DS-K1T6240 Series Face Recognition Terminal
The device supports multiple authentication methods including face, fingerprint, card, and PIN, with a capacity to store up to 3,000 faces, fingerprints, and cards each. Its face recognition speed is less than 0.2 seconds per user, with
DS-K1T6240 Series Face Recognition Terminal
- 4.3-inch LCD touch screen, 2 Mega pixel wide-angle lens
- Built-in Lithium battery, last for 3.5-5 hours
- Recognition distance: 0.3 to 3 m
- Face recognition duration < 0.2 s/User
- Face recognition accuracy rate ≥ 99%
- Multiple authentication methods, including face, card, QR Code etc.
- Supports ISAPI, ISUP 5.0, TCP/IP (IPv4 and IPv6)
- 4G and WiFi Option for Mobile T&A
Technical Specifications
System
| Operating System | Linux |
|---|
Display
| Size | 4.3 inch |
|---|---|
| Type | Touch Screen |
Video
| Lens | Dual-lens |
|---|---|
| Resolution | 2 MP |
| Video standard | PAL (Default) and NTSC |
Network
| Wired network | 10 M/100 M self-adaptive |
|---|---|
| 4G | Support (only on DS-K1T6240MGB-QR) |
Interface
| Network interface | 1 |
|---|---|
| Lock control | 1 |
| Exit button | 1 |
| Door contact input | 1 |
| Type-C USB | 1 |
| Sim card slot | 1 (only 4G version) |
Capacity
| Face capacity | 10,000 |
|---|---|
| Card capacity | 50,000 |
| Event capacity | 100,000 |
Authentication
| Face recognition accuracy rate | ≥ 99% |
|---|---|
| Face recognition duration | < 0.2 s per person |
| Face recognition distance | 0.3 to 3 m |
| Card type | Mifare 1 card |
| Card reading distance | 0 ~ 3 cm |
General
| Power supply | Built-in lithium battery or use 2 A (DC 12 V ~ DC 24 V) |
|---|---|
| Working environment | Indoor |
| Installation | Wall mount or hand held |
